600mm Threaded GR14 Anchor

50% END OF LINE SALE – Use code “threaded” at checkout (no further discounts apply).

The 600mm threaded GR14 offers extra depth for semi-permanent installs such as fencing, bollards, or structural fixings through small mounting holes. Install with a pilot hole and double-nut drive.
⚠️ Not designed for repeated use — thread damage from overtightening or reuse is not covered under warranty.
Best for long-term applications only.

50% END OF LINE SALE Use code "threaded" at checkout - No further discounts apply.

Skip to product information

50% OFF - END OF LINE- Threaded Ground Anchor Pack – 2 x 600mm GroundGrabba Pro I (Versatile Projects)

50% OFF - END OF LINE- Threaded Ground Anchor Pack – 2 x 600mm GroundGrabba Pro I (Versatile Projects)

check_circle Threaded shaft fits through 15–40 mm mounting holes

check_circle Threaded shaft fits through 15–40 mm mounting holes

check_circle Fits 24 mm deep impact socket wrench

check_circle Highest Peak pull-out tested harder ground: 299 kg*

*These values represent the absolute...

* These values represent the absolute peak readings recorded during our in‑house tests. For an accurate assessment, we recommend performing your own site‑specific tests and applying an appropriate safety margin. Results will vary depending on soil type, installation method, and conditions.

$79.99
$79.99 $159.99
redeem Limited Time Offer Sold out

check_circle An ideal solution for semi-permanent installations and relocatable fixtures

check_circle Installs into pilot holes where normal GroundGrabbas can’t pass through

check_circle Perfect for mounting plates with 15–40mm holes that won’t accept flighted shafts

check_circle Used where standard hex-head GroundGrabbas won’t suit the application

check_circle Requires a 24mm deep impact socket (not included) for deployment

check_circle Hot-dip galvanised to withstand long-term outdoor exposure

check_circle Backed by our lifetime replacement warranty for peace of mind

Closed-Hook-Tie-Down-Point-GroundGrabba-adaptor-galvanised-01

GroundGrabba | ClosedHook CH14 | Heavy Duty Tie Down Points | Hot Dip Galvanised

$4.99
Drill Bits | Masonry | Tungsten Tipped | 300-900mm

Drill Bits | Masonry | Tungsten Tipped | 300-900mm

$29.99
50% OFF - END OF LINE- Threaded Ground Anchor Pack – 2 x 600mm GroundGrabba Pro I (Versatile Projects)

50% OFF - END OF LINE- Threaded Ground Anchor Pack – 2 x 600mm GroundGrabba Pro I (Versatile Projects)

$79.99
$79.99 $159.99
SAVE 50% Sold out
View full details

More Information

check_box

What you Get

2x Commercial GroundGrabba Pro I - Threaded 600mm

check_box

How They Work

How They Work

Our engineered ground anchor flights (spirals) twist deep into the ground, creating a tree root–like hold. Once secure, you simply bolt down your base plate or item.

Our industrial-grade commercial threaded hex-less GroundGrabbas are designed so that, once driven into the ground, a portion of the threaded shaft remains above the surface—ready for attachment using the included washer and twin locknuts.

check_box

Set Up

check_box

Specifications

GR14UMT 600mm

  • Length 600mm
  • Shaft thickness 15mm
  • Made of 1018 Carbon Steel
  • Galvanised for anti-corrosion
  • Weight 1.4kg
  • Flights (spirals) 12.5mm wide + - 0.5mm, 3mm thick
  • Diameter flights 38.5mm + - 0.5mm
  • Can screw through 30mm hole up to 8mm thick
  • Fully welded flights
  • Nut - Socket size 24mm
  • Weight: 01.4kg
  • Dimensions: 60 × 4.5 × 4 cm
check_box

Grabbing Power

Hold Down Capacity

Please look at our tests below.

Our GroundGrabba ground anchors will anchor down up to 7X that of a similar sized hammer in spike stake!

See the complete test chart here

GroundGrabba Commercial M (GR14M)

Still not sure which GroundGrabba to use? Contact us 1300988655 or use this form.

IMPORTANT***Please note that these figures are a guide only.

The results are absolute peak readings and you should allow a decent safety margin.

Ground types vary. Through the depth of one ground anchor the ground can be of different densities and affect outcomes.

These all rely on correct deployment in dry conditions.

Please also note that you will experience even greater ground holding as time goes by and the earth resettles undisturbed.

check_box

Recommendations

Recommended Tools to hire or own to help with installation:

NB. These models were available at the time of writing.

**You will need a 24mm deep impact socket and set of spanners (for locking the two supplied nuts into themselves)**

For driving these into the ground, we recommend a high-torque impact wrench. Consider models like:

For driving these into the ground, we recommend a high-torque impact wrench. Consider models like:

  • Makita 40v TW001GZ-40v Brushless 3/4" Impact Wrench.
  • Milwaukee M18 FUEL 2867-20
  • Use a masonry drill at least the same length as the GR14 you choose for pilot holes in harder ground.

Important Note:

GroundGrabba Commercial range is designed for heavy-duty use with a tradie quality heavy-duty impact wrench.

Please note that these are not toys. Ensure you have a powerful drill, especially for hard ground conditions.

Uses & Benefits

Powerful Anchoring Where Standard Anchors Can’t Go

Need a deep-set anchor but your project’s mounting holes won’t fit a flighted GroundGrabba? The 600mm Threaded GroundGrabba was made for exactly that. Purpose-built to solve the common problem of small-hole compatibility, this threaded anchor delivers professional-grade hold in locations where hex-head or flighted options won’t work.

Designed for Narrow Access and Tough Terrain

This anchor is ideal for fixing through steel base plates, timber templates, brackets, and gear that has pre-drilled holes as small as 15–25mm. With no flights and a clean threaded shaft, it fits through compact openings where standard GroundGrabba Pro or Pro I anchors simply can’t pass.

The 600mm threaded model provides longer penetration and greater stability than our 450mm version, making it ideal for anchoring taller or heavier structures in harder ground—especially where depth matters.

Fast, Clean Installation

To deploy this anchor:

  1. Position your item or structure exactly where it needs to sit.
  2. Drill a pilot hole through your gear’s mounting hole and into the ground using a masonry bit suited to the soil type.
  3. Remove the item, then insert the 600mm anchor and drive it in using a 24mm deep impact socket (not supplied).
  4. Leave enough thread above ground to allow for a nut and washer to fasten your item securely.

Important: Do not overtighten the top nut. Excess torque may pull the anchor upward and reduce holding strength.

What Makes This Anchor Different?

  • Threaded Design – No flights means it fits where standard GroundGrabbas can’t
  • Longer Length – 600mm shaft provides added bite for heavier loads or taller items
  • Premium Steel – Manufactured from toughened steel and finished for durability in outdoor conditions
  • Removable & Reusable – Ideal for temporary installs, event setups, and field testing rigs
  • Fast No-Mess Setup – No concrete, no digging, no drying time

Perfect for Engineers, Installers & Field Techs

This model is especially useful for engineers, contractors, and installers who regularly need to mount gear or structures using existing holes or templates. It provides fast, secure fixing without modifying equipment or cutting oversized holes for standard anchors.

Ideal Applications

  • Art installations and public sculptures
  • Modular signage and light structures
  • Weather stations and scientific test rigs
  • Solar inverters and micro-pole systems
  • Audio-visual towers or cable trays
  • Temporary fencing, stanchions, and utility enclosures

Tooling & Compatibility

  • Socket size: 24mm (deep socket required)
  • Mounting hole compatibility: ~15–25mm internal diameter
  • Fasteners: Secure with appropriate nut and washer (not included)

If your project requires a 450mm option instead, check out the 450mm GroundGrabba Threaded Anchor. For extra bite and larger installs, consider stepping up to our 900mm version.

Why Threaded GroundGrabbas?

Threaded GroundGrabba anchors were developed for projects where our traditional hex head and wide 40mm flights are simply too large to pass through narrow openings. These anchors retain the same high-strength steel and installation simplicity of the GR14 ecosystem, but are streamlined for specialist applications.

They are not a ‘lesser’ option—just a different tool for a different job. And like all GroundGrabba anchors, they’re backed by our lifetime replacement warranty.

Installation Tips from the Field

"We use the 600mm threaded anchors to secure high-end equipment enclosures where pre-drilled holes leave no wiggle room. They save us so much time—no modifying gear, no dodgy retrofits." — Nathan B., AV Integrator

Need Help Choosing?

If you're unsure which anchor is best for your mounting hole size or site conditions, just get in touch. We’re happy to recommend the best fit—or ship a test unit to your site.

Engineered for clean installs, firm hold, and gear that won’t budge. The 600mm GroundGrabba Threaded Anchor gives you anchoring precision—without compromise.

Which GroundGrabba Is Right for You?

Model Length Socket Size Flights/Threaded? Use Case Summary
Junior 275mm 16mm hex (new series) Threaded Lighter-duty anchoring in firm to harder soils (not for sand); popular for most campers with smaller footprint needs
Pro 300/315mm 16mm hex (new) / 19mm (original) Flights / 25mm diameter General purpose for medium-to-firm soils; suitable for tents, gazebos, light gear
Up to 3× vertical pull-out hold over equivalent hammer-in stakes/tent pegs
Pro I 450/465mm 16mm hex (new) / 19mm (original) Flights / 35mm diameter Excellent for soft to medium soils; grass-topped sandy soils; step up from Pro for added depth/hold
Up to 7× vertical pull-out hold over equivalent hammer-in stakes/tent pegs
Pro II 600/615mm 16mm hex (new) / 19mm (original) Flights / 35mm diameter Best GR13 option for soft/loose sand; long reach for maximum camping-type loads
Up to 7× vertical pull-out hold over equivalent hammer-in stakes/tent pegs
Lite 400mm 19mm hex 3/4 length spiralled flights Light-duty in sand & soft to medium-to-firm soils; can work in grass-topped sand if used correctly; not for heavy loads or hard/rocky ground. Cordless drill use — not to be used with impact tools

Note: Always assess local soil conditions and loads; avoid rock/bedrock or impenetrable ground.

Product Details & FAQs

check_box

What’s included in this kit?

The pack includes:

2 × GroundGrabba Threaded Anchors (450mm)
2 or 4 × Matching nuts
2 × Matching washers

check_box

Ground Type

- Best for: soft to medium soils, including sandy sites (load-dependent)
- Not ideal: rock/bedrock or impenetrable ground
- Notes: good all-rounder; use 900mm for extra depth or higher loads

check_box

Tools Needed

Threaded GroundGrabbas must be installed with a 24mm deep impact socket and a high-torque impact wrench.
Do not attempt to use a standard drill or smaller socket, and avoid overtightening the nut once in place.

check_box

Hold Strength

600mm GR14 Commercial and Threaded GroundGrabbas deliver deeper bite and greater pull-out strength than the 450mm models.
They are well-suited to softer soils, loose clay, and sand where extra anchoring security is required.
Not intended for impenetrable rock or iron-hard ground.

For detailed pull-out results and technical information, see our Grabbing Power section.

check_box

Can you deliver to my address if I’m not in a metro area?

Yes. We ship Australia-wide. Regional and remote deliveries may take longer, and Star Track is our recommended courier for reliability outside metro areas. All orders are shipped with ATL (Authority to Leave) unless a signature is specifically requested at checkout.

check_box

When will my order arrive?

We dispatch from Tweed Heads, NSW several times a week. Metro areas are typically 1–3 business days depending on proximity to Brisbane/Eastern Seaboard; regional and remote deliveries may take longer. We recommend Star Track for reliability in regional and remote areas. Courier options and ETAs appear at checkout.

check_box

What warranty is included?

All steel GroundGrabba products come with a Lifetime Replacement Warranty against breakage in normal use. Accessories like bags, drill bits, and carabiners include a 12-month manufacturer’s warranty.

check_box

What is your return policy?

We back every purchase with a 100% risk-free 12-month return policy. If you’re not satisfied, you can return your GroundGrabba products within 12 months for a full refund or replacement (conditions apply).

From the founder:

Hi, I'm David Levine, inventor of GroundGrabba. In 2017, Susu and I set out to create purpose-built ground anchors. Today, our range secures everything from tents to tiny homes. We back our steel anchors with a Lifetime Replacement Warranty* and a 100% RISK-FREE 12-month return policy. Whatever you need to anchor, we'll keep you grounded.
